|Trailer weight (Unladen)||2.950T (approx.)|
|Tipping body||Sides – 3mm thk. HARDOX, Floor – 5 mm thk of HARDOX.
Top hinged door with suitable locking arrangement.
|Wet kit||Shall include Pump, Tank, return line filter, Tipping valve and Hydraulic hoses.
Operating pressure 170 BAR.
Multi Stage Cylinder: Model: FE 129-3-03640-001A-K1529.
|Surface preparation||Tipper surface shall be Shot blasted and cleaned.|
|Painting||One coat of primer and one coat of finish quick dry enamel paint with colour of customer choice.|
|Other fitments||Reflectors on both sides and rear shall be provided as per CMVR.|
